Plot Climate Metric Data

Source: R/splnr_plotting_climate.R
splnr_plot_climData.Rd

The splnr_plot_climData() function creates a spatial plot of climate metric information from an sf object. It provides a customizable visualization using ggplot2 and viridis color palettes.

Usage

splnr_plot_climData(
  df,
  colInterest,
  colorMap = "C",
  plotTitle = " ",
  legendTitle = "Climate metric"
)

Arguments

df

An sf object containing the climate metric information. It must have a geometry column.

colInterest

A character string specifying the name of the column in df that contains the climate metric data to be plotted.

colorMap

A character string indicating the viridis color map to use (e.g., "A", "B", "C", "D", "E"). See https://ggplot2.tidyverse.org/reference/scale_viridis.html for all options. Defaults to "C".

plotTitle

A character string for the subtitle of the plot. Defaults to " " (a single space, effectively no subtitle).

legendTitle

A character string for the title of the legend. Defaults to "Climate metric".

Value

A ggplot object representing the spatial plot of the climate metric.

Details

This function is designed to visualize spatial data that contains a specific climate metric. It expects an sf object (df) with a geometry column and the climate metric data in a column specified by colInterest. The plot uses a continuous color scale (viridis) to represent the metric values across the planning units.

This function can be easily integrated into a larger plotting workflow or used independently to inspect climate data distributions.

Examples

if (FALSE) { # \dontrun{
# Assuming 'dat_clim' is an existing sf object in your package
# with a column named "metric" or another relevant climate metric.

# Example: Plot climate data using "metric" column
plot_climate_metric <- splnr_plot_climData(
  df = dat_clim,
  colInterest = "metric",
  plotTitle = "Annual Climate Warming",
  legendTitle = "Warming (°C/year)"
)
print(plot_climate_metric)

# Example with a different color map
plot_climate_alt_cmap <- splnr_plot_climData(
  df = dat_clim,
  colInterest = "metric",
  colorMap = "D", # Using 'D' for a different viridis palette
  plotTitle = "Climate Metric (Alternative Colors)"
)
print(plot_climate_alt_cmap)
} # }
